Description
| Size | 6055*2990*2896 |  |
| Internal dimensions | 5895*2830*2500 | |
| Weight | 1600kg | |
| 2.3mm frame | Top frame 160mm |
Baking varnish hanging head 3.0mm * 480 C-type steel 1.0mm * 5 square tubes: 30 * 30 * 1.0mm * 1, 20 * 20 * 1.0mm * 2 upper beam: L = 5580 mm 2.3mm, upper secondary beam: L = 2670 mm 2.3mm |
| Bottom frame 160mm |
Baking varnish hanging head 3.0mm * 4 square tube: 100 * 50 * 1.0mm * 9 pieces 40 * 40 * 1.0mm * 1 piece lower beam: L = 5580mm 2.3mm lower secondary beam: L = 2670mm 2.3mm |
|
| Column 160 * 210 | Baking varnish 160 * 210 * 2526 mm 2.3mm * 4 pieces, stiffener 2.5mm * 2 L-shaped connector * 8 | |
| Color steel capping | Color steel tile | |
| PE resin moisture-proof film, 75 mm glass wool insulation quilt | ||
| Suspended ceiling | Ceiling tile | 7 sheets of 0.3mm thick 831 ceiling tiles |
| Color steel angle aluminum | The ceiling tile is made of the same material and is used for fixing the ceiling tile. | |
| Floor | Cement slab | Specification of 18mm cement fiber board: 1179 * 2820mm * 5 |
| Interior decoration | Internal corner line | White gray color steel finished column internal corner 2510mm * 4 |
| Skirting | PVC white skirting * 3 pieces | |
| The door | Glass door | Size: 900 * 2000 mm single |
| Window | Optional | Customizable shapes and sizes |
| Wallboard | / | Corrugated board |
| Auxiliary materials | Auxiliary materials | Screws, pin drills, internal box connections, connection plates, neutral silicone weatherproof sealant |
| National standard, European standard, American standard and Australian standard are optional for power distribution system | Light | LED ceiling strip light * 2 |
| Voltage | Various standards to choose from | |
| Complete set of two-core circuit | Main line: 6 ㎡, air conditioning line: 4 ㎡, socket line: 2.5 ㎡, lamp line: 1.0 ㎡ | |
| Switch | Single opening * 1 | |
| Socket | 3-socket (16 A) * 1; 5-socket (10 A) * 2 | |
| Electric Distribution | PVC distribution box * 1, 32A leakage protector * 1, industrial socket * 1, circuit breaker * 1 |
